Three-in-one Dehumidification Dryer

Three-in-one Dehumidification Dryer is a highly efficient equipment that integrates dehumidification, drying and feeding functions. It is widely used in the plastic processing industry, such as injection molding, extrusion, blow molding and other production processes. It is specially used to process plastic raw materials to ensure the quality stability of raw materials during the processing.

Introduction to Three-in-one Dehumidification Dryer

Features of Three-in-one Dehumidification Dryer

1. Space saving

Three-in-one Dehumidification Dryer integrates the three functions of dehumidification, drying and feeding into one device. Compared with the traditional combination of separate equipment, it occupies a smaller floor area and provides greater flexibility for the layout of factory workshops.

2. Improve efficiency

The design of this equipment makes the dehumidification, drying and conveying process of plastic raw materials more compact and coherent. The dehumidified air is directly used for drying, and the dried raw materials can be conveyed immediately, reducing the energy loss and time waste in the intermediate links, thereby significantly improving the production efficiency of the entire plastic processing process.

3. Stable quality

The equipment can accurately control parameters such as drying temperature, humidity and conveying speed to ensure that the moisture content of plastic raw materials is stable during the processing process and meet the processing requirements, thereby helping to improve the quality stability of plastic products.

Technical Parameter

Model	Capacity（L）	Capacity（KG）	Process Air Flow（m³h）	Process Heater（kw）	Regen.Blower（kw）	hedtntg（Kw）	Regen.Heater（kw）	Feed Fan（kw）	Hopper	Dimensions（CM）	Weight
KF-GCD25/50	38	25	50	0.4	0.2	3.6	2.4	0.75	6	11565155	320
KF-GCD50/80	76	50	80	0.75	0.2	3.6	3.6	0.75	6	13079185	375
KF-GCD75/120	115	75	120	1.1	0.2	3.6	3.6	0.75	6	13079185	405
KF-GCD100/120	153	100	120	1.1	0.2	5.4	3.6	0.75	6	13079185	442
KF-GCD150/150	230	150	150	1.5	0.2	6	3.6	0.75	6	13579200	475
KF-GCD200/200	307	200	200	2.2	0.4	12	5.4	1.5	12	13579200	560
KF-GCD300/200	461	300	200	2.2	0.4	15	5.4	1.5	12	13579200	585
KF-GCD400/300	615	400	300	3.75	0.4	18	7.2	1.5	12	205100279	635
KF-GCD500/400	769	500	400	4	1.5		10.9	2.2	12		-
The following machines are dehumidifier + European barrel dryer split
KF-GCD600/500	923	400	300	3.75	0.4	18	7.2	1.5	12	205100279	635
KF-GCD700/500	1076	600	400	5.5	0.75	21	7.2	1.5	12	205100279	660
KF-GCD800/700	1230	600	400	5.5	0.75	21	7.2	1.5	12	205100279	660

Advantages of Three-in-one Dehumidification Dryer

1. Reduced energy consumption

Through integrated design, the Three-in-one Dehumidification Dryer reduces the transmission loss of energy between different equipment and achieves efficient energy utilization, thereby reducing energy consumption costs in the production process.

2. Reduced risks

The fully enclosed design of the equipment can effectively prevent the dried raw materials from being damp again due to contact with the outside air, avoiding product quality problems caused by damp raw materials and reducing quality risks in the production process.

3. Improved production efficiency

Stable raw material quality and efficient production processes make the production process smoother, reduce downtime caused by equipment failure or raw material problems, and thus improve overall production efficiency.

Detials

Application Scenarios

Three-in-one Dehumidification Dryer is widely used in the following fields:

Plastic processing industry: such as injection molding, extrusion, blow molding and other production processes, to ensure that plastic raw materials reach the ideal dry state before processing.

Plastic modification industry: used to process various engineering plastics to improve product quality and performance.

Plastic recycling industry: to efficiently dehumidify and dry recycled plastics so that they can be put back into production.

FAQ

Q: Is the maintenance cost of Three-in-one Dehumidification Dryer high?

A: The design of the Three-in-one Dehumidification Dryer focuses on the convenience of maintenance. Daily maintenance mainly includes regular cleaning and inspection of key components. As long as the operation manual is followed for standardized operation and regular maintenance, the maintenance cost can be kept at a low level.

Q: Is the equipment suitable for processing plastic raw materials in high humidity environments?

A: Yes, the equipment has a strong dehumidification capacity and can effectively reduce the moisture content of the raw materials even in high humidity environments to ensure that they reach the ideal dry state.

Q: Does Three-in-one Dehumidification Dryer support customization?

A: Yes, we provide customized services and can adjust the parameters and functional configuration of the equipment according to the specific needs of customers to meet the requirements of different production processes.
